Lift Products Inc Stainless Steel SXTLP
Stainless Steel SXTLP
Ideal for use in wash down areas, the SXTLP ground entry lift table has a passivated sanitary finish and all dead end spaces have been eliminated.
In addition to the many ergonomic benefits derived by using lift tables, the USDA Approved SXTLP also meets the complex requirements demanded by the food processing, chemical and pharamaceutical industries.
The SXTLP is constructed out of T304 stainless steel and has totally enclosed dual hydraulic lift cylinders. With a lowered height of just 0.5", the lift can be ground loaded with a stainless pallet jack, removing the need for additional equipment.
Standard Features
-
Heavy-Duty T304 S.S. Construction
-
Beveled Low-Profile Platform
-
Relief Valve to Prevent Overloading
-
Control Valve for Controlled Descent in Case of Electrical Failure
-
Self-Contained Power Unit
-
Safety Up-Down Foot Pedal Control
-
USDA Approved
-
115 Volt Single Phase Hydraulic Drive W/Power Unit
-
Narrow 2.5" Wide Sides for Easy Loading/Unloading
-
Totally Enclosed Dual (Synchronized) Hydraulic Lift Cylinders
-
Pickle Passivated Finish
Options
-
3 Phase Power
-
Roll Through Platform
-
Side Guards
-
Maintenance Locks
-
Hand Controls
-
Mounted Controls
-
Specifications
| Model | Vertical Travel |
Capacity | Height | Platform Size |
Up Speed |
Base Frame |
Motor | Voltage | |
|---|---|---|---|---|---|---|---|---|---|
| Lower | Upper | ||||||||
| SXTLP-25 | 36" | 2,500 lbs | 0.5" | 37" | 42" x 48" | 20 sec | 48.25" x 54.75" | 1 HP | 115 |
