Instagrid GO 36 DV Portable Battery Power Supply
The Instagrid GO 36 DV is a professional portable battery power supply designed for demanding applications. Lightweight, robust, and powerful, it provides 3,600W rated output with peak power up to 18,000W. Whisper-quiet operation (below 30 dB) with no exhaust fumes makes it ideal for indoor and outdoor professional use.
Dokumentation
Key Features
- 3,600W rated output power (30A) with 18,000W peak power
- 2,074 Wh battery capacity for extended runtime
- Whisper-quiet operation below 30 dB (fanless)
- Fast charging: 0-80% in under 4 hours, 0-100% in under 5 hours
- IP44 rainproof rating for outdoor use
- Lightweight at 46 lb / 21 kg
- 2x NEMA 5-20 (20A) output receptacles
- Instagrid Accessories Outlet for expanded connectivity
- Overload protection up to 300% (10,800W for 6.5 seconds)
Technical Specifications
| Nominal Battery Capacity | 2,074 Wh (24 packs / 86.4 Wh each) |
| Weight | 46 lb / 21 kg |
| Dimensions | 16.7 x 8.3 x 16.5 in / 424 x 210 x 420 mm |
| IP Class | IP44 / UL Rain Test (rainproof) |
| Protection Class | Class II / double-insulated |
| Noise Emission | Below 30 dB(A) / whisper-quiet (fanless) |
| Receptacles | |
| Output Receptacles (120 V AC) | 2x NEMA 5-20 |
| Accessories Outlet | Instagrid Accessories Outlet |
| Input Receptacle | Neutrik powerCON® TRUE1 TOP |
